Version: Generation 1

Professional Version

Preparation​

1. Start Sync​

Right foot outward, then back to normal

2. Stop Sync​

Right foot inward, then back to normal

3. Continue Sync​

Right foot outward again, then back to normal

⚠️ Notes

  1. When using legs for control, ensure the controller is within VR view.
  2. Commands take effect after the leg completes the action and returns to normal.

Control Robot Movement​

1. Robot Movement​

Forward, Backward, Left, Right​

  • Lift left toe and hold, robot moves forward.
  • Lift left heel and hold, robot moves backward.

  • Rotate left foot left and hold, robot turns left.
  • Rotate left foot right and hold, robot turns right.

Ascend and Descend​

  • Lift right toe and hold, robot ascends.
  • Lift right heel and hold, robot descends.

2. Robot Arm Posture Control​

Maintain End Posture, Arm Position Follows​

Both feet outward and hold

Maintain Arm Position, End Posture Follows​

Both feet inward and hold
